CFS OT1Z : On-tank 1-zone
Complete fermentation sets CFS OT1Z : On-tank 1-zone
The CFS OT1Z complete fermentation sets are pre-configured sets that include all what is necessary to fermentation, maturation and storaging of beer, cider, wine or similar alcoholic beverages. They are equipped with several classical cylindrical-conical tanks, one compact liquid cooler and temperature measuring and regulation system with separated digital regulator on each tank .
On-tank control system + Single cooling zone ( or two dependent connected zones) on each tank.
Example set CFS OT1Z : CFSOT1-10xCCT1000C Complete beer fermentation set with 10x CCT-1000C, on-tank control
The complete beer fermentation set. This set includes all equipment necessary for professional production of beer using the fermentation and maturation process from wort produced before by the brewhouse. This set is also designed for production of cider from fruit or carbonated wine.
Assembling of the set is very easy. The installation does not require any professional workers – there is needed only adequate handling equipment for moving and installation of heavy containers (cylindrical-conical fermenters) on place after delivering of the set. All wires, temperature measuring and regulation equipment (exclude covered central control cabinet and cooler) operate with safety voltage 24V, therefore they can be installed by customer using the installation manual. Therefore the price of the set does not include the installation work.
The CFSOT1-10xCCT1000C complete fermentation set includes :
-
Cylindrical-conical tank Classic CCT-1000/1170 L (insulated 2-jacket) × 10pcs
-
Compact water chiller-heater 10.7 kW
-
Tank overflow protection kit for cooler
-
Local tank temperature manual measuring & control system for 10 pcs of single cooling zone fermenters
-
Main compact manifold set 3/4″ with manometer for connect CWC to 5x 1/2″ branches
-
Compact manifold set 1/2″ for connect CWC to 2 cooling zones × 5pcs
-
Plastic Hose for water/glycol 19-24mm × 30meters
-
Plastic Hose for water/glycol 12-17mm × 70meters
-
Hose insulation 25-37mm × 30meters
-
Hose insulation 18-30mm × 70meters
-
Ball Valve for water/glycol M1/2″-H1/2″ × 40pcs
-
Hose clamp 20-32mm for hose 3/4″ × 4pcs
-
Hose clamp 12-22mm for hose 1/2″ × 40pcs
-
Pipe Fitting Coupler 2xG1/2″F × 30pcs
-
Assembling manual for easy installation without brewery specialists
I. Complete fermentation sets with one-cooling-zone CC-tanks 500 liters, one glycol cooler and on-tank control system :
[simple-rss feed=”https://eshop.czechminibreweries.com/product-category/cfs/ot1z/ot1z-cct500c/feed/?post_type=product” limit=”15″ show_date=”0″ hide_description=”0″ show_images=”1″ hide_url=”0″ amount_of_words=”20″]
II. Complete fermentation sets with one-cooling-zone CC-tanks 1000 liters, one glycol cooler and on-tank control system :
[simple-rss feed=”https://eshop.czechminibreweries.com/product-category/cfs/ot1z/ot1z-cct1000c/feed/?post_type=product” limit=”15″ show_date=”0″ hide_description=”0″ show_images=”1″ hide_url=”0″ amount_of_words=”20″]
III. Complete fermentation sets with one-cooling-zone CC-tanks 1500 liters, one glycol cooler and on-tank control system :
[simple-rss feed=”https://eshop.czechminibreweries.com/product-category/cfs/ot1z/ot1z-cct1500c/feed/?post_type=product” limit=”15″ show_date=”0″ hide_description=”0″ show_images=”1″ hide_url=”0″ amount_of_words=”20″]
IV. Complete fermentation sets with one-cooling-zone CC-tanks 2000 liters, one glycol cooler and on-tank control system :
[simple-rss feed=”https://eshop.czechminibreweries.com/product-category/cfs/ot1z/ot1z-cct2000c/feed/?post_type=product” limit=”15″ show_date=”0″ hide_description=”0″ show_images=”1″ hide_url=”0″ amount_of_words=”20″]
V. Complete fermentation sets with one-cooling-zone CC-tanks 3000 liters, one glycol cooler and on-tank control system :
[simple-rss feed=”https://eshop.czechminibreweries.com/product-category/cfs/ot1z/ot1z-cct3000c/feed/?post_type=product” limit=”15″ show_date=”0″ hide_description=”0″ show_images=”1″ hide_url=”0″ amount_of_words=”20″]
VI. Complete fermentation sets with one-cooling-zone CC-tanks 4000 liters, one glycol cooler and on-tank control system :
[simple-rss feed=”https://eshop.czechminibreweries.com/product-category/cfs/ot1z/ot1z-cct4000c/feed/?post_type=product” limit=”15″ show_date=”0″ hide_description=”0″ show_images=”1″ hide_url=”0″ amount_of_words=”20″]
VII. Complete fermentation sets with one-cooling-zone CC-tanks 6000 liters, one glycol cooler and on-tank control system :
[simple-rss feed=”https://eshop.czechminibreweries.com/product-category/cfs/ot1z/ot1z-cct6000c/feed/?post_type=product” limit=”15″ show_date=”0″ hide_description=”0″ show_images=”1″ hide_url=”0″ amount_of_words=”20″]
VIII. Complete fermentation sets with one-cooling-zone CC-tanks 8000 liters, one glycol cooler and on-tank control system :
[simple-rss feed=”https://eshop.czechminibreweries.com/product-category/cfs/ot1z/ot1z-cct8000c/feed/?post_type=product” limit=”15″ show_date=”0″ hide_description=”0″ show_images=”1″ hide_url=”0″ amount_of_words=”20″]
Prices of other configurations on demand (other volumes, types or numbers of tanks, cooling more equipment using one chiller etc.)
